UC 314 D1 NSK
The picture is for illustration only
3.448 Kč
4.172 Kč s DPH
1 Pcs In stock
Product info
insert bearings
Brand: NSKInner diameter: 70.00
Outer diameter: 150.00
Total width: 78.00
Detailed product information
UC 314 D1 NSK
| Inner diameter (d) [mm]: | 70 |
|---|---|
| Outer diameter, diameter of rod, shaft (D) [mm]: | 150 |
| Total bearing width [mm]: | 78 |
| Brand: | NSK |
| Seal: | contact NBR with additional cover sheet on both sides |
| Category: | Insert bearing |
| Material: | standard bearing steel |
| Cage: | pressed steel cage |
| Outer ring construction: | rounded surface of the outer ring |
| Inner ring construction: | inner ring widened on both sides, clamped with set screws |
| Weight: | 3,95 |
| Rolling elements: | steel balls |
| Inner ring width [mm]: | 78 |
| Outer ring width (C) [mm]: | 41 |
| Precision: | P0 /PN / ABEC1 - basic accuracy class |
