3305 BNRTNG NSK
The picture is for illustration only
772 Kč
934 Kč s DPH
10 Pcs In stock
Product info
angular contact ball bearings
Brand: NSKInner diameter: 25.00
Outer diameter: 62.00
Total width: 25.40
Detailed product information
3305 BNRTNG NSK
| Inner diameter (d) [mm]: | 25 |
|---|---|
| Outer diameter, diameter of rod, shaft (D) [mm]: | 62 |
| Total bearing width [mm]: | 25,4 |
| Brand: | NSK |
| Material: | standard bearing steel |
| Cage: | polyamide cage |
| Contact angle: | Contact angle 25° |
| Outer ring construction: | groove with the snap ring in the outer ring |
| Inner ring construction: | inner ring with 1:30 taper hole |
| Clearance - preload: | C0 / CN - standard / normal radial internal clearance (standard range) |
| Weight: | 0,32 |
| Rolling elements: | steel balls |
| Precision: | P0 /PN / ABEC1 - basic accuracy class |
| Seal: | without seal - open bearing |
| Category: | double-row angular contact ball bearing |
