7020 A5TR/A5TRV1VDUDMP3 NSK
The picture is for illustration only
0 Kč
0 Kč s DPH
16 Pcs In stock
Product info
angular contact ball bearings
Brand: NSKInner diameter: 100.00
Outer diameter: 150.00
Total width: 24.00
Detailed product information
7020 A5TR/A5TRV1VDUDMP3 NSK
| Inner diameter (d) [mm]: | 100 |
|---|---|
| Outer diameter, diameter of rod, shaft (D) [mm]: | 150 |
| Total bearing width [mm]: | 24 |
| Brand: | NSK |
| Material: | standard bearing steel |
| Cage: | textite cage |
| Contact angle: | Contact angle 25° |
| Outer ring construction: | standard - without flange, without groove |
| Inner ring construction: | inner ring with cylindrical hole |
| Arrangement: | DUD |
| Clearance - preload: | M - middle preload |
| Weight: | 4,35 |
| Rolling elements: | steel balls |
| Precision: | P3 - dimensional accuracy P4/ABEC7, running accuracy P2/ABEC9 |
| Seal: | non-contact NBR on both sides |
| Category: | Single-row angular contact ball bearing |
