7006 CSN24TRV1VS-01 /SULP3 MTS X NSK
The picture is for illustration only
4.241 Kč
5.132 Kč s DPH
4 Pcs In stock
Product info
angular contact ball bearings
Brand: NSKInner diameter: 30.00
Outer diameter: 55.00
Total width: 13.00
Detailed product information
7006 CSN24TRV1VS-01 /SULP3 MTS X NSK
| Inner diameter (d) [mm]: | 30 |
|---|---|
| Outer diameter, diameter of rod, shaft (D) [mm]: | 55 |
| Total bearing width [mm]: | 13 |
| Brand: | NSK |
| Category: | Single-row angular contact ball bearing |
| Material: | standard bearing steel |
| Cage: | textite cage |
| Contact angle: | Contact angle 15° |
| Outer ring construction: | standardní - bez příruby, bez drážky na vnějším průměru |
| Inner ring construction: | inner ring with cylindrical hole |
| Arrangement: | SU |
| Clearance - preload: | C0 / CN - standard / normal radial internal clearance (standard range) |
| Weight: | 0,114 |
| Rolling elements: | ceramic balls |
| Grease filling: | approx. 15% free space in the bearing |
| Precision: | P3 - dimensional accuracy P4/ABEC7, running accuracy P2/ABEC9 |
| Seal: | non-contact NBR on both sides |
